Entirely novel and environmentally friendly energy technologies
Self-running running and zero emission generators which are based on autonomous hydraulic oscillations and the ram pump principle
Last update 29 March 2024
This self-running and zero emission energy technology is based on a specific type of constructions which are operated with water (or another fluid), or under water, or under a high internal water or fluid pressure. These systems - also called self-running ram pumps - generate usable mechanical, electric and / or thermal energy via autonomous hydraulic oscillations. Self-running ram pumps were, for example, constructed and advanced by the Russian inventor Dr. V. Marukhin and his co-workers. There are various kinds of constructions and sizes. For example, a steel tube design with 80 cm height and 20 cm diameter which is operated with an internal fluid pressure and oscillation frequency of about 3000 bar and 3000 Hz, respectively, can generate a permanent electric output power of several 100 kW. Two examples of such types of self-running generators and their specifications:
Image from page 10 of a presentation (40 pages, 3 MB pdf) from May 2021 by Adolf Schneider about ram pumps and generators based on self-running hydraulic oscillations
AR-500 (EGM-H-P-500-20) Output power 500 kW Output voltage 6 kV Height 30 cm Diameter 14 cm Weight 20 kg Maximum tilt angle 60 degrees
AR-1000 (EGM-H-P-1000-21) Output power 1000 kW Output voltage 12 kV Height 42 cm Diameter 15 cm Weight 40 kg Maximum tilt angle 60 degrees
Image and technical specifications from page 34 of a presentation (40 pages, 3 MB pdf) from May 2021 by Adolf Schneider about ram pumps and generators based on self-running hydraulic oscillations
Besides
an oscillating fluid under high pressure these generators comprise also
a gas buffer which is likewise oscillating under high pressure. The
fluid is for example water or glycerine and the gas is for example air
or nitrogen. After assembling such a generator the high internal fluid
and gas pressure can be achieved by a high pressure pump.
The generators which operate under a high internal fluid and gas pressure cannot be simply switched on or off. To initiate the self-running fluid and gas oscillations it is necessary to apply a specific high pressure pulse for a short time. That is realized by an electrically ignited explosion of about 2 g gun powder. The resulting pressure wave is transferred into the generator via a shock valve. That procedure requires special skills and for safety reasons an environment / space / laboratory which is protected against explosion. Once the self-running fluid and gas oscillations are started it is not necessary to stop them periodically, even if there are no electrical loads. Therefore the special starting procedure is usually required just once.
For safety reasons the steel tube is always designed for a pressure which is twice as as high as the operating pressure.
The
mechanical energy of the fluid and gas oscillations is
converted into electric energy by piezoelectric transducers. Their performance decreases over time and therefore the usable maximum output power of a
generator diminishes annually by a few percent. The piezoelectric transducers
generate a high DC voltage such as 12 kV. It can be converted into a
convenient AC form of electricity by using an appropriate custom-made
DC / DC converter (e.g. for 12 kV --> 1 kV) and an appropriate DC / AC
converter (e.g. for 1 kV DC --> 400 V / 50 Hz). The dimensions and
weight of the converter are much larger than that of the generator. The
following picture shows an example of a DC / AC converter.
DC / AC converter of the type
PVS 980 from ABB. Output power up to 2 MW. Dimensions and weight 3.2 x 2.4 x 1.5 m and 3500 kg, respectively. Image source: Ref1 or a presentation (40 pages, 3 MB pdf) from May 2021 by Adolf Schneider
The autonomously running generators developed by Dr. M. Marukhin and his co-workers are already in use at some undisclosed industrial customers.
The Swiss company TransAltec AG intends to acquire a general license for the most recent version of 1 MW generators for all countries apart from Southeast Asia and make some demonstration generators available which can be viewed and inspected on request. Some specifications of the most recent version of 1 MW generators: height 42 cm, diameter 15 cm, weight 40 kg, estimated final price about 1000 Euro / kW. However, the implementation of this intention is meanwhile stuck because of the imposed sanctions against Russia.
The undisclosed customers have not reported their experiences with their generator and their associated DC / DC converter and DC / AC converter. Therefore several items are not yet concretely known, namely the design of an appropriate DC / DC converter, the behavior of the generators and converters under various conditions such as a resistive, capacitive, and / or inductive load, and the power stability and safety over a long period of time. Another delicate item is the start of the generators by an electrically ignited explosion of about 2 g gun powder. Is that always reliable and safe, especially when it has to be performed at a customer site ?
Comments concerning the operation principle of self-running and zero emission generators which are based on hydraulic water (fluid) oscillations: The author of this website and report assumes that these and any other self-running energy technologies extract
usable energy from an everywhere present form of energy which is called space energy, space-time energy, vacuum energy, or ether energy as described in an information document about entirely novel and environmentally friendly energy technologies. The tapping of this form of energy happens probably via the
earth`s gravitational field which acts on the water (fluid) molecules and / or via
electromagnetic fields that act at the atomic level between or on water
(fluid) molecules.
References and further information:
German-language report on pages 15 - 17 in the January / February 2022 issue of the German-language journal NET-Journal (ISSN 1420-9292)
German-language report on pages 14 and 15 in the November / December 2021 issue of the German-language journal NET-Journal (ISSN 1420-9292)
German-language report on page 30 in the May / June 2021 issue of the German-language journal NET-Journal (ISSN 1420-9292)
German-language report on pages 20 - 24 in the March / April 2021 issue of the German-language journal NET-Journal (ISSN 1420-9292)
German-language report on pages 18 and 19 in the January / February 2021 issue of the German-language journal NET-Journal (ISSN 1420-9292)
German-language report on page 18 in the January / February 2020 issue of the German-language journal NET-Journal (ISSN 1420-9292)
Presentation from May 2021 by Adolf Schneider about ram pumps and generators based on self-running hydraulic oscillations (40 pages, 3 MB pdf): https://novam-research.com/resources/HEG-Presentation-English_May-2021.pdf . It can be downloaded also via http://www.borderlands.de/Links/HEG-Presentation-English.pdf
Presentation from May 2021 by Adolf Schneider about a small 20 kW generator
based on self-running hydraulic oscillations (14 pages, 1 MB pdf): https://novam-research.com/resources/HEG_Small-20kW-device_May-2021 . It can be downloaded also via http://www.borderlands.de/Links/Cola-Device.pdf
German-language slide set of a talk by Adolf Schneider about generators based on undamped hydraulic oscillations on 4 October 2020 at a conference about novel energy technologies and related topics in Stuttgart in Germany (55 slides or pages, 3 MB pdf): https://novam-research.com/resources/Generatoren-basierend-auf-hydraulischen-Schwingungen_Vortrag-von-Adolf-Schneider_Kongress-Stuttgart_4-Okt-2020.pdf . See also pages 24 and 25 in a German-language report in the November / December 2020 issue of the NET-Journal (ISSN 1420-9292) about the just mentioned conference (10 MB pdf, in German, see pages 24 and 25): https://novam-research.com/resources/Kongress-Stuttgart_2-bis-4-Okt-2020_Bericht.pdf
Book "The Eureka Machine - The Key to the Energy Future from Dr. V. V. Marukhin", authors Adolf and Inge Schneider, editor Dr. Peter Eschevers, first English edition, 2018, Jupiter Publishing House, ISBN 978-3-906571-33-1: https://jupiter-verlag.ch/shop/detail_neu.php?artikel=133&fromMain=j or https://www.goodreads.com/book/show/40879715-the-eureka-machine . This book in German (ISBN 978-3-906571-32-4): https://jupiter-verlag.ch/shop/detail_neu.php?artikel=132&fromMain=j
The following pdf slide set from a talk by Adolf Schneider about novel energy technologies on 3 November 2016 at the World Clean Energy Conference 2016 in Geneva in Switzerland presents on pages 25 - 32 the ram pump principle and the generators from Dr. V. Marukhin and his co-workers (file size about 2 MB): https://novam-research.com/resources/Novel-energy-technologies_Talk-by-Adolf-Schneider-at-WCEC-on-3-Nov-2016_Slide-set.pdf
Video: https://yadi.sk/d/9CN509gHhoWgq
Previous website innovenergy.org in Russian and English does not exist anymore
German-language information in the website of the Swiss company TransAltec AG: https://transaltec.ch --> Produkte im Angebot --> Hydraulischer Energie-Generator
German-language fact sheet / information from the Swiss company TransAltec AG: https://www.transaltec.ch/pdfs_aso/Projekt%20HEG-1000kW-TA-240321.de.pdf
Paper "Some research results about a possible hydraulic ram as a source of electric energy without using fuel" by V. Marukhin and V. Ivanov: http://www.borderlands.de/Links/Marukhin-Ivanov231115.pdf
Paper about a hydraulic ram pump from Adolf Schneider (in German): http://www.borderlands.de/Links/BeschreibungResonanzwidderAS051115.pdf
Acknowledgement:
The author of this website thanks Adolf and Inge Schneider for various reports, presentations, and communications about this type of novel energy technology.
